Oil Well Perforator, SDPR Super Deep Penetration Reactive Perforator

Reactive Perforator generates a secondary reaction in the perforation tunnel thanks to proprietary liner metallurgy and charge design, which receives its own cleaning action, resulting in clean and open perf tunnels with fractured tunnel tip. The result is incredible perforating efficiency, superior productivity and enhanced infectivity.

Applications:

1. All reservoir types

2. Limited Entry Perforation

3. Heterogeneous Pay Zone

4. Re-perforation &/or Depleted Zones

Main Features:

1. Clean, Open Tunnels Independent of Rock Type & Rock Properties

2. Debris- free tunnels without depending on underbalance

3. An ideal flow path between the reservoir and the well bore and higly beneficial to inflow performance.

4. Dramatic improvements in stimulation treatments thanks to fracturing of the tunnel tip.

Performance Index

Casing OD (mm): 140

Gun Size OD (mm): 102

Phasing (deg): 90

Shot Density (spm): 16

E.H. (Concrete) (mm): 13.8

Pene. (Concrete) (mm): 1392

Temperature Rating (°C/2h): 163

Specifications

★ API registered

Tiptop was established in the year of 2006, located in the center of China, Xi’an City, which is an ISO certified comprehensive manufacturer & distributor in the field of Oil & Gas upstream, downhole drilling tools, downhole fishing tools, downhole mud motor, and servicing the worldwide drilling companies, EPC contractors and oil companies. With our great diligence & years of experiences, we have built a long term cooperation with clients from North America, Middle East, Europe, Southeast Asia and other areas.

-One stop procurement service at more favorable prices

Being in the field of oilfiled for more than 13 years , Tiptop team can offer customers with whole package requirements in favorable prices , which are supported by Tiptop qualified vendors .

-Strict quality control & Continuous after-sales service

All of Tiptop supplied products are from API certified manufacturers. For each enquiry, from order placement to final delivery, no matter for the whole package or small spare parts, we have internal inspection team to ensure the superior quality, strong packing & timely delivery. Any TPI inspection are available with Tiptop from SGS/BV/TUV/DNV etc..

Besides,Thoughtful and prompt after-sales service will be provided to guarantee customerS' benefits .
