    SS95 / SS105 Downhole Drilling Tools Sour Service Line Pipe 2 3 / 8 '' ~ 6 5 / 8''

    Ask Lasest Price
    Brand Name : TIPTOP
    Model Number : Sour Service Drill Pipe
    Certification : MTC
    Price : Negotiation
    Payment Terms : T/T, L/C, D/A, D/P
    Supply Ability : 2000 tons per month
    Delivery Time : 20-90 days
    • Product Details
    • Company Profile

    SS95 / SS105 Downhole Drilling Tools Sour Service Line Pipe 2 3 / 8 '' ~ 6 5 / 8''

    Sour Service Drill Pipe SS95/SS105, 2 3/8''~6 5/8'', Downhole Drilling Tools


    Besides all standard API grades, we can also supply special sour service grades, such as SS-95 and SS-105, which are manufactured to meet the most stringent service requirements of clients.


    Along with the increasing of well depth of drilling, the more complex stratum will emerge, especially of the emerging of sulfur stratum which will harmfully impact the safety of well drilling operation. Once hydrogen sulfur emerges, drilling tools would break suddenly in a very short time period and it will be very harmful to well drilling operation. Pipe body, tool joint and welding line of sour service drill pipe must be tested against hydrogen sulfur. Yield strength of pipe body, tool joint and welding line is strictly limited between 724MPa~827MPa. Sour-service performance of pipe body and tool joint must be at least 85% SMYS, and at least 80%SMYS for welding line as per NACE 0177 Spec A.


    Pipe Body Properties
    GradeYield Strength (Mpa/Ksi)Tensile Strength (Mpa/Ksi)Hardness (HRC)Impact (Charpy V-notch Type A) min.
    AverageIndividual
    Min.Max.Min.Max.Max.Max.Min.JoulesFt-Lbs
    SS75517/75655/95655/95793/1152224-7050
    SS95665/95758/110724/105896/1302527188059
    SS105724/105827/120793/115965/1402829218059

    Tool Joint Properties (Mpa/Ksi)Tool Joint Weld Zone Impact
     Min.Max. Impact Min. Ave (J)Impact Min. Av (ft-lb)
    Yield Strength758/110862/125Tool Joint9066
    Tensile Strength862/1251000/145Weld Zone2720

    Welcome to contact us to order your sour service drill pipe.
