    ZTQ203 Rig Floor Handling Tools API 7K Drill Pipe Dual Purpose Casing Power Tong

    Ask Lasest Price
    Brand Name : TIPTOP
    Model Number : Dual Purpose Power Tong
    Certification : Inspection Certificate
    Price : Negotiation
    Payment Terms : T/T, L/C, D/A, D/P
    Supply Ability : 500 pc per month
    Delivery Time : 5~30 days
    • Product Details
    • Company Profile

    ZTQ203 Rig Floor Handling Tools API 7K Drill Pipe Dual Purpose Casing Power Tong

    Rig Floor Handling Tool API 7K Drill Pipe and Casing Dual Purpose Power Tong


    Dual-purpose power tongs is applicable to tripping operation and running-in casing operation in the drilling activities in petroleum and mining. It is a new power tongs dependently developed according to the requirements from oilfield customers. The power tong integrates the function of drill pipe power tong and casing power tong. It can meet the requirements under the operation of frequent tripping or connecting single pipe. In addition, it can be used to run in the casing with small diameter. During the conversion between the two operations, it is not necessary to replace the equipment. It can increase the wellhead operation efficiency and reduce the labor intensity. The tongs are designed and manufactured according to API 7K.


    ModelZTQ203-100/35ZTQ203-100/35ⅢZTQ203-125/35ZTQ203-125/35Ⅲ
    Size rangeDrill pipemm127-203127-203127-203127-203
    in3 1/2''~5'', 8''3 1/2''~5'', 8''3 1/2''~5'', 8''3 1/2''~5'', 8''
    Casingmm127-196127-196127-196127-196
    in5''~7''5''~7''5''~7''5''~7''
    Max. torqueDrill pipekN.m100100125125
    ft.lbf73760737609220092200
    CasingkN.m35353535
    ft.lbf25816258162581625816
    Speed(High gear)rpm40404040
    Speed(Low gear)rpm2.72.72.72.7
    Air pressureMPa0.5—0.9
    psi72—130
    Pressure ratingMPa16.616.6 20.7
    psi24002400 3000
    Flow ratingL/min114114 114
    gpm3030 30
    Shifting distancemm0—15000—1500
    in0—590—59
    Travel distancemm0—30000—3000
    in0—1180—118
    Lifting distancemm0—8000—800
    in0—31.50—31.5
    Weightkg2450360027003800
